This LoRa Panel Antenna provides reception and transmission of signals in the 865-868 MHz frequency band. Both VSWR and axial ratios are both excellent and allow the user to achieve the maximum performance for an antenna of this type.
The antenna is housed in a heavy-duty radome enclosure that can be directly wall mounted.
An optional articulating mount allows either wall or mast mounting. Flat panel antenna with circular polarization, designed to be integrated into RFID gates and checkpoints.
Its robust design with IP65 protection class is suitable for industrial applications.
| Electrical | |
| Frequency Range | 865-868MHz |
| F/B Ratio | ≥20dB |
| Gain | 6dBi |
| V.S.W.R | ≤1.5 |
| Radiation | Direction |
| Horizontal Beam width | 90° |
| Vertical Beam width | 90° |
| Polarization | RHCP |
| Lightning Protection | DC Grounded |
| Maximum Input Power | 50W |
| Impedance | 50Ώ |
| Connector | SMA Female |
| Cable Type | 30cm |
| Cable Length | RG58U |
| Antenna Radome Material | ASA |
| Mounting way | Wall Mount |
| Mechanical | |
| Dimensions | 130x130x20mm |
| Weight | 238g |
| Operating Temperature | -40℃ to+70℃ |
| Rated Wind Velocity | 60m/s |
| RoHS Compliant | YES |
This directional antenna is designed for indoorused.as a part of signal booster kit.
It's a high gain antenna suited for broadcasting indoor signal over a wide area.
Point it to the direction you need coverage, it will cover farther distance and provide much stable signal.
