This is the integration of a high performance GPS whip antenna and a low noise amplifier into a very low profile/ extremely compact/ fully waterproof enclosure which, when connected to a GPS receiver with 2.2~5V.
DC antenna power, provides excellent signal amplification and out-band filtering & rejection, provide 1.5~3.1V input Voltage is available. Antennas feature ultra-durable watertight enclosures and can withstand strong vibration.
The L type bracket installation can make the antenna fixed better.
| Electrical | ||
| Antenna | Frequency Range | 1575.42MHz±3MHz |
| Band Width | CF±5MHz | |
| V.S.W.R | ＜1.5 | |
| Polarization Type | RHCP | |
| Gain | 2dBic(Zenith) | |
| Impedance | 50Ώ | |
| Axial Ratio | 3dB(max) | |
| Dimension | 25*25*4mm | |
| LNA | Gain | 28±2 dB Typical |
| Noise Figure | <1.5dB | |
| DC Voltage | 2.2-5.0V | |
| DC current | 5-15mA | |
| V.S.W.R | ＜2.0 | |
| Mechanical | Housing | Black |
| Cable | RG174 | |
| Length | 3M(Can be customized) | |
| Connector | SMA Male(Can be customized) | |
| Antenna Radome Material | ABS | |
| Mount way | Wall Mount | |
| Environmental | Dimensions | Φ50×49mm |
| Weight | 115g | |
| Operating Temperature | -40℃~+80℃ | |
| Humidity | UP to 95% | |
| Waterproof | IP65-67 | |
| RoHS Compliant | YES | |
