The 3G wall-mount antena is an indoor or outdoor directional antenna. Designed for wall-mounted applications, this antenna is compact whilst offering robust RF performance.
Complementing 3G routers and devices, this antenna operates across the sub-3 GHz bands from 800 MHz to 3.0 GHz frequencies.
Measuring just 42mm in height and 165mm in length, it can be surface-mounted onto a metal or non-metal surface, but more typically can be wall-mounted using a metal L-bracket. With gain of 6 dBi in the lowest band, 9 dBi in highest band, this antenna offers consistent performance and can be paired with LMR195, LMR240 low loss cables to extend the distance between the antenna and the router.
| Electrical | |
| Frequency Range | 800-960/1710-2500MHz |
| F/B Ratio | ＞20dB |
| Gain | 6/9dBi |
| V.S.W.R | ≤2.0 |
| Radiation | Direction |
| Horizontal Beamwidth | 50°/50° |
| Vertical Beamwidth | 80°/60° |
| Polarization | Vertical |
| Lightning Protection | DC Grounded |
| Maximum Input Power | 50W |
| Impedance | 50Ώ |
| Connector | N Female |
| Cable Type | RG58U |
| Cable Length | 30cm |
| Antenna Radome Material | ABS |
| Mounting Way | Wall Mount |
| Mechanical | |
| Dimensions | 165x155x42mm |
| Weight | 270g |
| Operating Temperature | -40℃ to+70℃ |
| Rated Wind Velocity | 60m/s |
| RoHS Compliant | YES |
