The AC-Q7027I27 antenna delivers stable high omni-directional gain and across all 2G(GSM),3G and 4G (LTE),cellular bands from 700MHz to 2.7GHz.
This high performing antenna can be used for all cellular devices and will not require changing antennas when deploying from country to country or technology to technology like CDMA to GSM or 3G to 4G.
Being magnetic mount it is designed to be mounted on a ground plane for optimal performance
| Electrical | |
| Frequency Range | 698-960/1710-2700MHz |
| Gain | 9dBi |
| V.S.W.R | ≤2.5；Max2.8 |
| Radiation | Omni-Direction |
| Polarization | Vertical |
| Maximum Input Power | 50W |
| Impedance | 50Ώ |
| Connector | SMA Male |
| Cable Type | RG58U |
| Cable Length | 3M |
| Antenna Radome Material | Steel wire |
| Mount way | Magnetic |
| Mechanical | |
| Dimensions | Φ65x450mm |
| Weight | 566g |
| Operating Temperature | -40℃ to+70℃ |
| RoHS Compliant | YES |
The 4G LTE magnetic antenna range is a great solution for temporary fitsituations.
A compact radiating element housed in a moulded sheath is mounted onto a magnetic base to facilitate 4G/LTE communications.
This versatile antenna operates across the major cellular and wifi bands.
