FAKRA connectors have been especially designed to fulfill the tough requirements of the automotive industry.A sophisticated coding system of the standard plastic housing offers 13 mechanical and colored codings and one neutral coding.
FAKRA connectors are constructed in jack or plug gender with 50 Ohm impedance.
FAKRA connectors are available in straight or right angle versions, as well as, mountless options.
These FAKRA connector designs include crimp/solder or solder attachment methods.
| Electrical Specifications | ||
| Frequency | 0-4GHz | |
| VSWR | 1.5 MAX | |
| Polarity | Standard | |
| Connector Series | FAKRA | |
| Connector Gender | Jack | |
| Impedance | 50 Ohm | |
| Operating Voltage (AC) | 335V | |
| Dielectric Withstanding Voltage (AC) | 1000V | |
| Inner Conductor DC Resistance | 6mOhms | |
| Outer Conductor DC Resistance | 2.5mOhms | |
| Insulation Resistance | 1000mOhms | |
| Temperature Range | -40°C to +85°C | |
| Body Style | Straight | |
| Attachment Method | Solder | |
| MATERIAL & PLATING | ||
| Shell | Plastic | |
| Contact pin | Phosphor Bronze | Gold |
| Insulation | PTFE | |
| Outer Conductor | Brass | Nickel |
FAKRA (Fachkreis Automobil) Connectors are an industry standard product that is designed to exceed and satisfy the demanding environmental requirements of the worldwide automotive industry.
The FAKRA connector standard has evolved to compliment these developments, and is based on the SMB design which can operate up to a Frequency of 6 GHz.
The housings have a locking feature that prevents accidental disconnection due to restricted wire routing or high environmental vibration.
