This antennas is deisgned to operate on both 2.4 GHz and 5.8 GHz. This dual band design makes them ideal for use with many of the new generation 802.11ac wireless access points and routers.
WiFi 4x MIMO ceiling mount Antenna is designed for 802.11a/b/g/n/ac networks.
This antenna contains four antenna elements for true multiple-input-multiple output performance.
All of which support both bands of operation making the antenna usable at 2.4 GHz, 5 GHz or both.
Each antenna element covers 2400-2500 MHz with 4 dBi gain & 4900-5850 MHz with 5 dBi.
This Ceiling Mount Antenna can provide a network of efficient WiFi MIMO network coverage throughout a building. It features a low-profile unobtrusive white ABS radome which blends in with the environment. Cable Assemblies can be customized to different lengths.
| Electrical | |
| Frequency Range | 2400-2500/5150-5850MHz |
| Gain | 4/5dBi |
| V.S.W.R | ≤1.8 |
| Radiation | Omni-Direction |
| Polarization | Vertical |
| Maximum Input Power | 50W |
| Impedance | 50Ώ |
| Connector | 4xRP SMA Male |
| Cable Type | RG316 |
| Cable Length | 1M |
| Antenna Radome Material | ABS |
| Mounting way | Ceiling Mount |
| Mechanical | |
| Dimensions | Φ145x40mm |
| Weight | 188g |
| Operating Temperature | -40℃ to+80℃ |
| RoHS Compliant | YES |
This Ceiling Mount WiFi antenna covers 2.4 GHz and 2.4/5.8 GHz dual band.
Ceiling Mount WiFi antenna is popular in office environments as it is aesthetically pleasing and located in a relatively secure area.
The Ceiling mount antenna has low profile housing and comes with rugged mounting hardware kit.
