868MHz High Gain Networking Yagi Antenna for RFID applications where high performance is required from a small size. Vertical or Horizontal Polarisation.
This yagi antenna can be rotated 90° to offer polarisation in both planes.
A vertical pole will offer vertical polarisation, a 90°, an elbow adaptor or horizontal pole is required for horizon-tal polarisation.
Supplied with N-Type Connector with 30cm RG58 cable.
| Electrical | |
| Frequency Range | 865-870MHz |
| Band width | 5MHz |
| F/B Ratio | ＞20dB |
| Gain | 8dBi |
| V.S.W.R | ≤1.5 |
| Radiation | Direction |
| Horizontal Beam width | 70° |
| Vertical Beam width | 55° |
| Polarization | Vertical |
| Lightning Protection | DC Grounded |
| Maximum Input Power | 50W |
| Impedance | 50Ώ |
| Connector | N Female |
| Cable Type | RG58U |
| Cable Length | 30cm |
| Antenna Radome Material | ABS |
| Mount way | Pole |
| Diameter of Installation Pole | Ø30~Ø50mm |
| Mechanical | |
| Dimensions | 295x210x65mm |
| Weight | 500g |
| Operating Temperature | -40℃ to+80℃ |
| Rated Wind Velocity | 60m/s |
| RoHS Compliant | YES |
Yagi Antenna are available in different polarization.The antennas are most suitable for signal penetration.
Circular polarization gives stable connectivity in any environments & non line of site applications.
These antennas are designed by our in house team of experts for better signal reception,these can work in all weather condition.
