RFID antennas are used to read RFID tags in warehouses, production lines, retail stores, medical centers and hospitals, sporting events, etc.
The wide variety of RFID antennas provided by Dipole RFID have been chosen to meet the real needs of users, so you can find the right antenna for your application.
It is easy to mount on ceilings and walls, and its rugged grey housing is at home in both customer-facing and industrial settings. So you can achieve superior read zones around stockroom shelves,warehouse doorways and dock platforms – anywhere boxes and pallets are moving into and out of your facility.
| Electrical | |
| Operating Frequency | 865-868MHz |
| Band width | 3MHz |
| Gain | 7dBi |
| F/B Ratio | ≥18dB |
| Polarization | Circular |
| Horizontal Beam width | 65° |
| Vertical Beam width | 55° |
| V.S.W.R | <1.5 |
| Lightning Protection | DC Grounded |
| Radiation | Direction |
| Maximum Input Power | 100w |
| Impedance | 50Ω |
| Connector | N Female |
| Cable Type | RG58U |
| Cable Length | 30cm |
| Mountng way | Wall mount |
| Antenna Radome Material | ABS |
| Mechanical | |
| Dimensions | 207x180x45mm |
| Weight | 500g |
| Rated wind velocity(m/s) | 60m/s |
| Operating Temperature | -40℃ to+80℃ |
| RoHS Compliant | YES |
The panel antenna is ideal for transportation, warehousing, logistics, and asset tracking applications.
This is the best wave propagation RFID antenna when the tag orientation is known and fixed.
Since the RFID antenna continuously emits a wavelength the rotational field will eventually cover any tag that is in its path.
