5Ghz full band 30dBi Grid antenna is designed for the spread spectrum system. he dimension is incomplied with the plot of feed reflector. which ensure the antenna works in the best state. This antenna features high gain, long working distance, light weight, compact structure and good command in wind resistance. The wide band design of this antenna eliminates the need to purchase different antennas for each frequency. This simplified installations since the same antenna can be usedfor a wide array ofwireless applications. This antenna features 30 dBi of gain with a 4 degree beam-width. it can be oriented for either vertical or horizontal polarization. wo piece reflector grid is simple to assemble and significantly reduces shipping costs.
| Electrical | |
| Frequency Range | 5150-5850 MHz |
| F/B Ratio | ≥25dB |
| Gain | 30dBi |
| V.S.W.R | ≤2.0 |
| Radiation | Direction |
| Horizontal Beam width | 4° |
| Vertical Beam width | 6° |
| Polarization | Vertical or Horizontal |
| Lightning Protection | DC Grounded |
| Maximum Input Power | 100W |
| Impedance | 50Ώ |
| Connector | N Female |
| Antenna Radome Material | Aluminum Alloy |
| Mounting way | Pole Mount |
| Diameter of Installation Pole | Ø50~Ø70mm |
| Mechanical | |
| Dimensions | 600x900mm |
| Weight | 2.5KG |
| Operating Temperature | -40℃ to+70℃ |
| Rated Wind Velocity | 60m/s |
| RoHS Compliant | YES |
5.1/5.5/5.8GHz WLAN/WiMax Long-distance directional communication Point to point,Broad band, 23.5 dBi gain Compatible with vertical or horizontal polarization use for Wireless bridges.
Die cast aluminum grid, UV stable coat finish and Down-tilt bracket, Easy to mount;High quality Aluminum alloy structure provides the required stiffness.
Huge grid ensures antenna with high gain that a strong ability of receive and transmit signal;Point to Point, Point to Multi-point Sys Can be installed vertically or horizontally.
