The IP65-rated High-Gain LTE Panel Directional Antenna is made from weatherproof and corrosion- resistant material, and is suited for both indoor and outdoor applications.
LTE Panel Directional Antenna extends the coverage range of a wireless network in a single direction.
It is ideal for delivering extended access range.
| Electrical | |
| Frequency Range | 698-960/1710-2700MHz |
| Gain | 7/10dBi |
| F/B Ratio | 15/20dB |
| V.S.W.R | ≤1.8 |
| Radiation | Direction |
| Horizontal Beam width | 70°/75° |
| Vertical Beam width | 75°/60° |
| Polarization | Vertical |
| Lightning Protection | DC Grounded |
| Maximum Input Power | 50W |
| Impedance | 50Ώ |
| Connector | N Female |
| Cable Length | RG58U 30cm |
| Antenna Radome Material | ABS |
| Mounting way | Wall Mount |
| Mechanical | |
| Dimensions | 300x183x70mm |
| Weight | 754g |
| Operating Temperature | -40℃ to+60℃ |
| RoHS Compliant | YES |
Click to see 4g wall mount antenna list.
This wall mount panel antenna features up to 7/10 dBi gain and work with all 50ohm signal boosters.
30cm RG58U cable with N Female connector, come with wall mount bracket, no technical experience required, easy to install.
The wall mount antenna features an N-Female connector that facilitates the transfer of high-frequency information.
