High quality and durable high gain omnidirectional 142mm long antenna with 3meter coaxial cable and SMA connector.433MHz is a commonly used frequency band for all types of equipment that require little power, such as garage door openers, headphones, baby monitors and remote controls. Omnidirectional antennas are used in most consumer RF wireless devices, including cellular telephone handsets and wireless routers. Designed with a magnetic base. The antenna can be placed on any iron surface. horizontally or vertically. However, the vertical position is recommended for better signal.3meter coaxial cable with SMA connector for easy connection, so no extension is needed
| Electrical | |
| Frequency Range | 433MHz |
| Band width | ±3MHz |
| Gain | 2.5dBi |
| V.S.W.R | ≤2.0 |
| Radiation | Omni-Direction |
| Polarization | Vertical |
| Maximum Input Power | 50W |
| Impedance | 50Ώ |
| Connector | SMA Male(can be customization) |
| Cable Type | RG174 |
| Cable Length | 3M |
| Antenna Radome Material | PE |
| Mount way | Magnetic |
| Mechanical | |
| Dimensions | Φ29x142mm |
| Weight | 50g |
| Operating Temperature | -40℃ to+70℃ |
| RoHS Compliant | YES |
This UHF VHF Antenna Compatible with Microphone System Receiver Remote Digital Audio Mic Receiver Tuner UHF Ham Radio.
Antenna with 3 meter (10inch) coaxial cable with male SMA connector for easy connection, so no extension is needed.
The vertical position of the antenna is recommended for better signal.
