The 3G YAGI antenna is designed for use in GSM/GPRS/DCS/UMTS systems working in 800-2170Mhz.
AC-D1721Y15-22 series light aluminium alloy duty Yagi are factory assembled and adjusted for easy installation.
They feature light-wall tubing elements and machined aluminum blocks for the boom-to-element junctions.
Twelve element models are available. Economical, light weight installation and good performance.
| Electrical | |
| Frequency Range | 1710-2170MHz |
| F/B Ratio | ＞18dB |
| Gain | 15dBi |
| V.S.W.R | ≤1.5 |
| Radiation | Direction |
| Horizontal Beam width | 25° |
| Vertical Beam width | 25° |
| Polarization | Vertical |
| Lightning Protection | DC Grounded |
| Maximum Input Power | 50W |
| Impedance | 50Ώ |
| Connector | N Female |
| Cable Type | RG58U |
| Cable Length | 30CM |
| Antenna Radome Material | Aluminum Alloy |
| Mounting way | Pole Mount |
| Diameter of Installation Pole | Ø30~Ø50 mm |
| Mechanical | |
| Dimensions | 980x90x45mm |
| Weight | 500g |
| Operating Temperature | -40℃ to+80℃ |
| RoHS Compliant | YES |
This high gain wideband directional antenna covers all international cellular, mobile and wireless data bands.
Its configuration is suitable for various wireless communications systems.Tremendous improvement on reliability of celluar data Robust and weatherproof.
This Yagi is designed with 22 elements. It is designed for applications in DAS, Utilities, Oil & Gas, Mining, Industrial, Transportation, Irrigation, and many more.
