The Wifi dishes are made from casted aluminium and combine a high stability and rugged weatherproof and low wind load for a long endurance of the antennas.
Wide Band Operation,Vertically or Horizontally Polarized,Extremely Rugged for Extreme Environment.
Antenna is supplied together with the bracket, which is possible to set easily in both directions.
The Parabolic Dish Antenna systems offered by Wireless are constructed of an aluminum alloy dish with powder coat paint finish for excellent mechanical.
Drain holes are provided on the radome cover to help prevent moisture build-up inside the dish antenna
| Electrical | |
| Frequency Range | 2300-2700MHz |
| F/B Ratio | ≥26dB |
| Gain | 2x18dBi |
| V.S.W.R | ≤2.0 |
| Radiation | Direction |
| Horizontal Beam width | 25° |
| Vertical Beam width | 25° |
| Polarization | V/H or ±45° |
| Lightning Protection | DC Grounded |
| Maximum Input Power | 100W |
| Impedance | 50Ώ |
| Connector | 2xN Female |
| Cable Type | LMR195 |
| Cable Length | 100mm |
| Antenna Radome Material | Aluminium alloy |
| Mounting way | Pole |
| Diameter of Installation Pole | Ø30~Ø50mm |
| Mechanical | |
| Dimensions | Φ450mm |
| Weight | 2.8KG |
| Operating Temperature | -40℃ to+70℃ |
| Rated Wind Velocity | 60m/s |
| RoHS Compliant | YES |
2.4GHz UNII,ISM, applications2300-2700MHz Wireless LAN systems Point to Point, Point to Multi-point System.
Wireless Bridges Radio Local Area Networks (RLAN) appliciation IEEE 802.11b/g/n wireless LAN, WiFi systems.
Dual-polarised antenna feed with high isolation Wireless bridges and backhaul applications Rugged and Weatherproof.
