The dipole Antenna is primarily designed for use with WIFI modules.
It does not require a ground-plane to connect to. It has a quality robust TPE housing for use with wireless terminals.
The antenna has an SMA/RP SMA(M) connector.
It can be used straight or hinged 90 degrees. The antenna has a wide-band response and can also be used for 2400-2483MHz applications.
Electrical
| Frequency Range | 2400-2483MHz |
| Band Width | 83MHz |
| Gain | 2.5dBi |
| V.S.W.R | ≤1.5 |
| Radiation | Omni-Direction |
| Polarization | Vertical |
| Maximum Input Power | 5W |
| Impedance | 50Ώ |
| Connector | SMA Male |
| Antenna Radome Material | TPE |
Mechanical
| Dimensions | Φ8x108mm |
| Weight | 7g |
| Operating Temperature | -40℃ to+70℃ |
| RoHS Compliant | YES |
Bluetooth antenna are Send or receive signal to devices in all directions (360-degree horizontal beamwidth).
The dipole Antenna is primarily designed for use with WIFI modules.
This 2.4GHz swivel terminal antenna with good performance across the wireless frequency bands.
